Chapter 2. 2-10
Step 3: Remove the base from the monitor, refer to “Detaching the monitor base and
stand”.
Step 4: Attach the mounting bracket from the VESA compatible wall mounting kit
(100mm x100mm distance), VESA Mounting Screw M4 x 10 mm.
VESA hole
Step 5: Attach the LCD display to the wall, following the instructions in the
wallmounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket with minimum
weight/load bearing capacity of 7.8 kg (17.3 lbs).
