Replacing the USB connector
Make sure the following FRUs (or CRUs) have been removed.
“Replacing the computer display panel” on page 25
To remove the USB connector, do the following:
1. Detach 2 connectors
1 and remove 4 screws 2 .
Figure 11. Detaching connectors and releasing screws
2. Remove the 2 USB connectors 3 .
Figure 12. Removing the USB connectors
What to do next:
• To work with another piece of hardware, go to the appropriate section.
• To complete the installation or replacement, go to “Completing the parts replacement” on page 55.
Replacing the function board shield
Make sure the following FRUs (or CRUs) have been removed.
“Replacing the computer display panel” on page 25
28
Yoga A940Hardware Maintenance Manual
