Figure 28. Removing the mainframe
What to do next:
• To work with another piece of hardware, go to the appropriate section.
• To complete the installation or replacement, go to “Completing the parts replacement” on page 55.
Replacing the front bezel
Make sure the following FRUs (or CRUs) have been removed.
“Replacing the computer display panel” on page 25
To remove the front bezel, do the following:
1. Loosen 2 screws
1 and remove the EOU door assembly 2 .
Figure 29. Removing the EOU door assembly
2. Remove 3 screws 3 and remove the system housing top 4 .
38
Yoga A940Hardware Maintenance Manual
