Accessory decoder LS150 11
the right (marked with in Figure 2) otherwise the turnout will not
function properly!
Press push-button K1 to activate coil 1 and press push-button K2
to activate coil 2. This way you can control the turnout both
digitally with the LS150 or manually with the push-buttons K1 and
K2.
Only use voltage-free contacts for this procedure, e.g.
Reed contacts! The ROCO track 42518 is also suitable.
Note: The C terminals of different LS150s may not be
connected to each another!
Controlling the outputs
The LS150 will only activate one output at a time. Incoming
turnout commands are stored until they can be processed. If the
same LS150 receives several turnout commands in a row, which
cannot be processed simultaneously due to the pulse duration set,
the corresponding outputs are activated in the order received. This
feature is ideal for setting routes.
