Accessory decoder LS150 6
6
Power and DCC signal Inputs of the LS150
The LS150 is supplied with power via the AC input (≈). Use a
suitable transformer – we recommend the Atlas Generator.
Warning: AC voltage must be used to supply power to
the LS150. Do not use a DC supply as this can damage
the LS150.
The power of the transformer used must not exceed
45VA in order to guarantee the proper operation of the
short circuit load protection.
If you desire to use a transformer with a higher
amperage you must protect the LS150s with a 10 ohm
resistor (Radio shack part #271-1101)
The track outputs of a digital system (J,K for
Digital plus by Lenz
®
systems) must not be used to
supply the LS150 with power!
The LS150 receives its commands to activate a turnout from the
NMRA-DCC digital system track outputs connected to the LS150’s
J and K inputs.
