Lenze E82ZAFPC010 - Assignment of the terminals

Electrical installation
Assignment of the terminals
6
EDK82ZAFPC-010 DE/EN/FR 6.0 61

H2_BelegungAnschlKlemmen-klemmbesch-010
Assignment of the terminals
Terminal
X3.1/
Designation Function / level

PES Additional HF shield termination
A T/R(A) RS485 data line A
B T/R(B) RS485 data line B
Terminal
X3.2/
Designation Function / level
59 External DC voltage supply for the function module
 +24 V DC ± 10% (reference: GND1)
 Current consumption on 24 V DC: 80 mA
The current for looping through the supply voltage to other nodes
via terminal 59 must be max. 3 A.
7 GND1 Reference potential for X3.3/20
Terminal
X3.3/
Designation Function / level
7 GND1 Reference potential for X3.3/20
39 GND2 Reference potential for controller inhibit (CINH) at X3.3/28
28 CINH Controller inhibit
 Input resistance: 3.3 k Ω
 Start = HIGH (+12 ... +30 V)
 Stop = LOW (0 ... +3 V)
(reference: GND2)
20 DC voltage source for external supply of controller inhibit (CINH)
 +20 V (reference: GND1)
 I
max
= 10 mA
