System modules
AIF_IO_Management (node number 161)
Inputs_AIF_Management
13
257
EDBCSXA064 EN 3.2
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0126 MONIT CE0 3
Fault response regarding the
monitoring of communication
via AIF interface X1.
l Via C2382 you can select
whether controller inhibit
(CINH) or quick stop (QSP) is
activated when a CE0 fault
occurs.
255
0 TRIP
A communication error activates
the CE0 response set.
2 Warning
3 Off Monitoring switched off.
C2121 AIF:State
AIF status
More detailed information can
be found in the documentation
of the plugged−in fieldbus
module.
Read only
195
1 {1} 255 Binary interpretation reflects bit
states.
Bit 0 XCAN1_IN monitoring time
Bit 1 XCAN2_IN monitoring time
Bit2 XCAN3_IN monitoring time
Bit3 XCAN bus off
Bit4 XCAN operational
Bit5 XCAN pre−operational
Bit 6 XCAN warning
Bit 7 Assigned internally
