Lenze ECSxK001 series User Manual

System modules
AIF1_IO_AutomationInterface (node number 41)
Inputs_AIF1
13

261
EDBCSXA064 EN 3.2
System variables
Variable Data
type
Signal
type
Address Display
code
Display
format
Comments
AIF1_wDctrlCtrl Word ˘ %IW41.0 C0136/3 hex
AIF1_bCtrlB0_b
BOOL binary
%IX41.0.0
C0136/3 bin
AIF1_bCtrlB1_b %IX41.0.1
AIF1_bCtrlB2_b %IX41.0.2
AIF1_bCtrlQuickstop_b %IX41.0.3
AIF1_bCtrlB4_b %IX41.0.4
AIF1_bCtrlB5_b %IX41.0.5
AIF1_bCtrlB6_b %IX41.0.6
AIF1_bCtrlB7_b %IX41.0.7
AIF1_bCtrlDisable_b %IX41.0.8
AIF1_bCtrlCInhibit_b %IX41.0.9
AIF1_bCtrlTripSet_b %IX41.0.10
AIF1_bCtrlTripReset_b %IX41.0.11
AIF1_bCtrlB12_b %IX41.0.12
AIF1_bCtrlB13_b %IX41.0.13
AIF1_bCtrlB14_b %IX41.0.14
AIF1_bCtrlB15_b %IX41.0.15
AIF1_nInW1_a
integer analog
%IW41.1 C0856/1
dec [%]
AIF1_nInW2_a %IW41.2 C0856/2
AIF1_nInW3_a %IW41.3 C0856/3
AIF1_bInB0_b
...
AIF1_bInB15_b
BOOL binary
%IX41.2.0
...
%IX41.2.15
C0855/1
hex
AIF1_bInB16_b
...
AIF1_bInB31_b
%IX41.3.0
...
%IX41.3.15
C0855/2
AIF1_dnInD1_p
double
integer
position %ID41.1 C0857 dec [inc]
