Lenze ECSxK001 series User Manual

System modules
CAN_Synchronization (node number 102)
13

282
EDBCSXA064 EN 3.2
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0363 Sync correct. 1
CAN sync correction increment
 167
1 0.2 ms/ms
2 0.4 ms/ms
3 0.6 ms/ms
4 0.8 ms/ms
5 1.0 ms/ms
C0366 Sync Response 1
CAN sync response for interface
X4 (CAN)
The value "1" should always be
set!
 169
0 No response
1 Response
C0367 Sync Rx ID 128
CAN sync receipt ID for CAN bus
interface X4
 168
1 {1} 256
C0368 Sync Tx Id 128
CAN Sync transmission ID for
CAN bus interface X4
 442
 166
1 {1} 256
C0369 SyNc Tx time 0
CAN sync transmission cycle for
CAN bus interface X4
A sync telegram with the
identifier of C0368 is sent with
the cycle time set.
ECSxP: The setting is effected
automatically depending on
C4062!
 167
0 {1 ms} 65000 0 = switched off
C1120 Sync mode 0
Sync signal source
 166
0 Off Off
1 CAN sync Sync connection via interface X4
(CAN)
 170
2 Terminal sync Sync connection via terminal
X6/DI1
 171
C1121 Sync cycle 2
Synchronisation cycle
 166
1 {1 ms} 13
C1122 Sync phase 0.460
Synchronisation phase
 167
0.000 {0.001 ms} 6.500
C1123 Sync window 0.010
Synchronisation window
 169
0.000 {0.001 ms} 6.500
