System modules
CAN3_IO (node number 33)
13
295
EDBCSXA064 EN 3.2
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0356 CAN time settings for CAN bus
interface X4
163
1 CAN times 3000 0 {1 ms} 65000 CAN boot−up time:
Delay time after mains
connection for initialisation
through the master.
2 CAN times 0
CAN2...3_OUT cycle times:
Factor for the task time to send
process data telegram.
0 = event−controlled
transmission
3 CAN times 0
4 CAN times 20 Delay time for initial
transmission of the process data
objects 2 and 3 after the CAN bus
changed to "Operational"
C0357 Monitoring time for CAN1...3_IN
(CAN bus interface X4)
202
1 CE monit time 3000 1 {1 ms} 65000 CE1 monitoring time
2 CE monit time 3000 CE2 monitoring time
3 CE monit time 3000 CE3 monitoring time
C0863 Digital process data input words
for CAN bus interface X4
Hexadecimal value is bit−coded.
Read only
446
0000 {hex} FFFF
1 CAN IN bits Bit 0 ... Bit15 CAN1_IN: Process data input
word 1
2 CAN IN bits Bit 16 ... Bit 31 CAN1_IN: Process data input
word 2
3 CAN IN bits Bit 0 ... Bit15 CAN2_IN: Process data input
word 1
4 CAN IN bits Bit 16 ... Bit 31 CAN2_IN: Process data input
word 2
5 CAN IN bits Bit 0 ... Bit15 CAN3_IN: Process data input
word 1
6 CAN IN bits Bit 16 ... Bit 31 CAN3_IN: Process data input
word 2
C0866 Analog process data input words
(decimal) for CAN bus interface
X4
100.00% = 16384
Read only
446
1 CAN IN words −199.99 {0.01 %} 199.99 CAN1_IN word 1
2 CAN IN words CAN1_IN word 2
3 CAN IN words CAN1_IN word 3
4 CAN IN words CAN2_IN word 1
5 CAN IN words CAN2_IN word 2
6 CAN IN words CAN2_IN word 3
7 CAN IN words CAN2_IN word 4
8 CAN IN words CAN3_IN word 1
9 CAN IN words CAN3_IN word 2
10 CAN IN words CAN3_IN word 3
11 CAN IN words CAN3_IN word 4
