DFOUT_IO_DigitalFrequency (node number 22)
Inputs_DFOUT / Outputs_DFOUT
13

341
EDBCSXA064 EN 3.2
13.17.1.2 Configuration master frequency output signal
You configure the type of the master frequency output signal via C0540:
C0540 = 0 Output of an analog signal
Function The input signal DFOUT_nOut_vis interpreted as an analog signal [%] and is output as a
frequency signal on the master frequency output X8.
Scaling 100 % º (INT)16384 º C0011 (n
max)
Transmission
function
f[Hz] + DFOUT_nOut_v[%] @
C0030
100
@
C0011(n
max
)
60
DFOUT_nln_v + f[Hz] @
60
C0030
@
2
14
15000
Example
l DFOUT_nOut_v = 50 %
l C0030 = 3, this corresponds to a number of increments of 2048 increments/revolution
l C0011 = 3000 rpm
f[Hz] + 50% @
2048
100
@
3000
60
 + 51200Hz
C0540 = 1 Output of a speed signal
Function The input signal DFOUT_nOut_vis interpreted as a speed signal [rpm] and is output as a
frequency signal on the master frequency output X8.
Scaling 15000 rpm º (INT)16384
Transmission
function
f[Hz] + DFOUT_nOut_v[rpm] @
C0030
60
Example
l DFOUT_nOut_v = 3000 rpm
l C0030 = 3, this corresponds to a number of increments of 2048 increments/revolution
f[Hz] + 3000rpm @
2048
60
+ 102400Hz
C0540 = 2 Encoder simulation of the resolver with zero track in resolver position
Function l The function is used if a resolver is connected to X7.
l The encoder constant for output X8 is set in C0030.
l The output of the zero pulse with reference to the rotor depends on how the resolver is
mounted to the motor.
l The zero pulse can be shifted by +360 ° via C0545 (65536 inc = 360 °).
 Note!
The zero pulse can only be output with C0540 = 2 (encoder simulation of
resolver).
