Lenze ECSxK001 series User Manual

System modules
FCODE_FreeCode (node number 141)
13

348
EDBCSXA064 EN 3.2
System variables
Variable Data
type
Signal
type
Address Display
code
Display
format
Notes
FCODE_nC17_a
Integer
analog
%IW141.0
˘ ˘
default = 50 rpm
FCODE_nC26_1_a
%IW141.2 default = 0.00 %
FCODE_nC26_2_a
%IW141.3 default = 0.00 %
FCODE_nC27_1_a
%IW141.4 default = 100.00 %
FCODE_nC27_2_a
%IW141.5 default = 100.00 %
FCODE_nC32_a
%IW141.6 default = 1
FCODE_nC37_a
%IW141.7 default = 0 rpm
FCODE_nC108_1_a
%IW141.8 default = 100.00 %
FCODE_nC108_2_a
%IW141.9 default = 100.00 %
FCODE_nC109_1_a
%IW141.10 default = 0.00 %
FCODE_nC109_2_a
%IW141.11 default = 0.00 %
FCODE_nC141_a
%IW141.12 default = 0.00 %
FCODE_bC250_b BOOL binary %IX141.13.0 ˘ ˘ default = 0
FCODE_bC471Bit0_b
...
FCODE_bC471Bit15_b
BOOL binary
%IX141.14.0
...
%IX141.14.15
˘ ˘ default = 0
FCODE_bC471Bit16_b
...
FCODE_bC471Bit31_b
%IX141.15.0
...
%IX141.15.15
FCODE_nC472_1_a
...
FCODE_nC472_20_a
Integer analog
%IW141.16
...
%IW141.35
˘ ˘
default = 0.00 %
C0472/3 = 100.00 %
FCODE_nC473_1_a
...
FCODE_nC473_10_a
Integer analog
%IW141.36
...
%IW141.45
˘ ˘
default = 0
C0473/1,2 = 1
FCODE_dnC474_1_p
...
FCODE_dnC474_5_p
Double
integer
Position
%ID141.23
...
%ID141.27
˘ ˘ default = 0
FCODE_nC475_1_v
Integer velocity
%IW141.56
˘ ˘ default = 0
FCODE_nC475_2_v
%IW141.57
FCODE_bC135Bit0_b
...
FCODE_bC135Bit15_b
BOOL binary
%IX141.58.0
...
%IX141.58.15
˘ ˘ default = 0
