Appendix
Code table
14
388
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0061 Heatsink
temp
Heatsink temperature
Read only
208
−200 {1 °C} 200
C0062 Interior temp
Interior device temperature
Read only
209
−200 {1 °C} 200
C0063 Mot temp
Motor temperature
Read only
206
0 {1 °C} 200
C0064 Utilization
Device utilisation (I x t) over the
last 180 s
Only display
0 {1 %} 150 l C0064 > 100 % activates
OC5−TRIP.
l TRIP−RESET only is possible if
C0064 < 95 %.
C0065 U24 ext
External low−voltage supply
(U
24
)
Read only
0,0 {0.1V} 100,0
C0066 Motor load
Thermal motor load I
2x
t
Only display
214
0 {1 %} 250
C0067 Act trip Current fault (TRIP)
(in case of FAIL−QSP, warning and
message, "0" is displayed.)
Only display
242
C0070 Vp speedCTRL 3.0
Proportional gain of speed
controller (V
pn
)
141
0.00 { 0.01} 127.99
C0071 Tn speedCTRL 24.0
Reset time − speed controller
(T
nn
)
141
1.0 {0.5 ms} 6000.0
C0072 Td speedCTRL 0.0
Derivative gain of speed
controller (T
dn
)
141
0.0 {0.1 ms} 32.0
C0074 Dynamics 0
Pilot control of the current
controller for higher dynamics
136
0 Normal
1 Enhanced
C0075 Vp currCTRL 20.0
Proportional gain of current
controller (V
pi
)
The upper limit is
device−dependent.
136
0.00 {0.01 W} 381.80 ECSxS/P/M/A004
190.90 ECSxS/P/M/A008
95.46 ECSxS/P/M/A016
47.72 ECSxS/P/M/A032
31.82 ECSxS/P/M/A048
23.86 ECSxS/P/M/A064
