Lenze ECSxK001 series User Manual

Appendix
Code table
14

394
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0150 Status word 0
Device status word 1 (DCTRL)
Read only
 328
 239
0 {1} 65535 Controller evaluates information
as 16 bits (binary−coded)
Bit 0 Not assigned DCTRL_bStateB0_b
Bit 1 Pulse inhibit (IMP) DCTRL_bImp_b
Bit2 Not assigned DCTRL_bStateB2_b
Bit3 Not assigned DCTRL_bStateB3_b
Bit4 Not assigned DCTRL_bStateB4_b
Bit5 Not assigned DCTRL_bStateB5_b
Bit 6 n = 0 DCTRL_bNActEq0_b
Bit 7 Controller inhibit (CINH) DCTRL_bCInh_b
Bit 8 Device status bit 1 DCTRL_bStat1_b
Bit 9 Device status bit 2 DCTRL_bStat2_b
Bit10 Device status bit 3 DCTRL_bStat4_b
Bit11 Device status bit 4 DCTRL_bStat8_b
Bit12 Warning DCTRL_bWarn_b
Bit13 Message DCTRL_bMess_b
Bit14 Not assigned DCTRL_bStateB14_b
Bit15 Not assigned DCTRL_bStateB15_b
C0155 Status word 2 0
Status word 2 (advanced status
word)
Display only
0 {1} 65535 Controller interprets information
as 16 bit (binary coded)
Bit 0 Active fault
Bit 1 M
max
reached
Bit 2 I
max
reached
Bit 3 Pulse inhibit(IMP)
Bit 4 Ready for operation (RDY)
Bit 5 Controller inhibit (CINH)
Bit 6 TRIP active
Bit 7 Initialisation
Bit 8 Motor direction of rotation (Cw/CCw)
Bit 9 Not assigned
Bit 10 Not assigned
Bit 11 Not assigned
Bit 12 Not assigned
Bit 13 Not assigned
Bit 14 Not assigned
Bit 15 Not assigned
