6
ENGLISH
Commissioning
3 Commissioning
3.1 Battery Operation
The EPM programmer is immediately ready for operation. It is delivered with 4 batteries
(1.5 V mono-cells).
3.2 Changing Batteries
For battery operation you need four mono-cell (D size) with 1.5V each. In order to access the battery compartment, you
must open the housing of the EPM programmer.
epm007
Open the battery compartment of the EPM programmer
1. Remove the 5 screws on the bottom of the EPM programmer
2. Remove the EPM Programmer base plate carefully.
epm004
Insert the batteries into the battery compartment
1. Insert the batteries into the battery compartment as shown in figure above.
- Pay attention to the correct polarity of the batteries!
2. Replace the base plate carefully and secure the housing with the 5 screws.
