Display code Short designaon Default seng Seng range Address Category
└ P190.08 OBD version - - (Read only) 0x2000:008 general
└ P190.10 PU rmware ver. - - (Read only) 0x2000:010 general
└ P190.11 PU rmware type - - (Read only) 0x2000:011 general
└ P190.12 PU bootlder ver. - - (Read only) 0x2000:012 general
└ P190.13 PU bootlder type - - (Read only) 0x2000:013 general
└ P190.14 Mod. rmware - - (Read only) 0x2000:014 general
└ P190.15 FW revision nr. - - (Read only) 0x2000:015 general
└ P190.16 Bootloader revNo - - (Read only) 0x2000:016 general
P191.00 Device name My Device Text 0x2001 general
P192.xx Device module
└ P192.04 CU type code - - (Read only) 0x2002:004 general
└ P192.05 PU type code - - (Read only) 0x2002:005 general
└ P192.06 CU serial number - - (Read only) 0x2002:006 general
└ P192.07 PU serial number - - (Read only) 0x2002:007 general
P197.00 Protect. status - - (Read only) 0x2040 general
P198.00 Status load. par - - (Read only) 0x2827 general
P200.00 Control select. Flexible I/O [0] Selecon list 0x2824 general
P201.xx Stnd. setpoints
└ P201.01 Freq. setp. src. Analog input 1 [2] Selecon list 0x2860:001 general
└ P201.02 PID setp. src. Keypad [1] Selecon list 0x2860:002 general
└ P201.03 Torque setp.src. Analog input 1 [2] Selecon list 0x2860:003 general
P202.xx Keypad setpoints
└ P202.01 KP freq.setpoint 20.0 Hz 0.0 ... 599.0 Hz 0x2601:001 general
└ P202.02 KP PID setpoint 0.00 PID unit -300.00 ... 300.00 PID unit 0x2601:002 general
└ P202.03 KP torq.setpoint 100.0 % -400.0 ... 400.0 % 0x2601:003 general
P203.xx Start/stop confg
└ P203.01 Start method Normal [0] Selecon list 0x2838:001 general
└ P203.02 Start at powerup O [0] Selecon list 0x2838:002 general
└ P203.03 Stop method Standard ramp [1] Selecon list 0x2838:003 general
P208.xx Mains sengs
└ P208.01 Mains voltage 230 Ve [0] Selecon list 0x2540:001 general
└ P208.02 LU warn. thresh. 0 V * 0 ... 800 V 0x2540:002 general
└ P208.03 LU error thresh. x V - (Read only) 0x2540:003 general
└ P208.04 LU reset thresh. x V - (Read only) 0x2540:004 general
└ P208.05 OU warn. thresh. 0 V * 0 ... 800 V 0x2540:005 general
└ P208.06 OU error thresh. x V - (Read only) 0x2540:006 general
└ P208.07 OU reset thresh. x V - (Read only) 0x2540:007 general
P210.00 Min. frequency 0.0 Hz 0.0 ... 599.0 Hz 0x2915 general
P211.00 Max. frequency Device for 50-Hz mains:
50.0 Hz
Device for 60-Hz mains:
60.0 Hz
0.0 ... 599.0 Hz 0x2916 general
P220.00 Accelerat.me 1 5.0 s 0.0 ... 3600.0 s 0x2917 general
P221.00 Decelerat.me 1 5.0 s 0.0 ... 3600.0 s 0x2918 general
P222.00 Accelerat.me 2 5.0 s 0.0 ... 3600.0 s 0x2919 general
P223.00 Decelerat.me 2 5.0 s 0.0 ... 3600.0 s 0x291A general
P224.00 Ramp 2 thresh. 0.0 Hz 0.0 ... 599.0 Hz 0x291B general
P225.00 QSP dec. me 1.0 s 0.0 ... 3600.0 s 0x291C general
P226.xx S-ramp char.
└ P226.01 Smoothing factor 0.0 % 0.0 ... 100.0 % 0x291E:001 general
P230.xx Opcal tracking
└ P230.01 Start detecon Stop [0] Selecon list 0x2021:001 general
└ P230.02 Blink. duraon 5 s 0 ... 3600 s 0x2021:002 general
P300.00 Motor ctrl mode VFC open loop [6] Selecon list 0x2C00 general
* Default seng depending on the size. Firmware version 05.00.00.00
