6 Elektrische Installation
Verbindungsaufbau über RS485 (LECOM−B)
EDKMF2102 DE/EN/FR 8.0
32
H2_VerbindungRS485_LECOM−verbindg zu AR−Master
2102LEC018
RS485−Schnittstelle über Steckerleiste, 4−polig
Klemme Bezeichnung Belegung
71 T/R(B) RS485
72 T/R(A) RS485
88 S−C Kapazitive Schirmung nach PE
89 S Direkte Schirmung nach PE
