EDKMF2102 DE/EN/FR 8.0
45
ausklappbild−Legende
Pos. Description Detailed
information
Communication module EMF2102IBC−V001, LECOM−A/B (RS232/RS485)
Communication module EMF2102IBC−V002, LECOM−B (RS485)
Communication module EMF2102IBC−V003, LECOM−LI (optical fibre)
Communication module EMF2102IBC−V004, LECOM−A (RS232)
E82ZBL−C: communication module EMF2102IBC−V004, LECOM−A (RS232),
with diagnosis terminal
68
Status indicator (green) voltage supply
82
Status indicator (yellow) data reception
Status indicator (yellow) data transmission
Status indicator (red/green) of the controller
Plug connector, connection for external voltage supply
63
RS485 plug connector, RS485 interface connection
71
RS232 Sub−D socket, RS232 interface connection
67
Fixing screw
PE connection (only with 82XX)
Output power selector (normal/high)
73
Optical fibre receiver (black)
Optical fibre transmitter (white)
73
Nameplate 55
