Product code of MCA asynchronous servo motor
Example M C A 10 C 40 - RS0 B0
Meaning Variant Product code
Product family Motor M
Type Compact servo motors C
Version Asynchronous A
Motor frame size Square dimension 102 mm 10
Square dimension 130 mm 13
Square dimension 142 mm 14
Square dimension 165 mm 17
Square dimension 192 mm 19
Square dimension 200 mm 20
Square dimension 214 mm 21
Square dimension 220 mm 22
Square dimension 260 mm 26
Overall length I
...
X
Rated speed rpm x 100 05
...
42
Inverter mains connecon 3 x 400 V
Degree of protecon: IP54 / IP65
-
3 x 400 V
Degree of protecon: IIP23
H
Feedback SinCos absolute value encoder, single-turn, EnDat
AS2048-5V-E
ECN
SinCos absolute value encoder, mul-turn, EnDat
AM32-5V-E
EQI
SinCos absolute value encoder, mul-turn, EnDat
AM2048-5V-E
EQN
Resolver RS0
Safety resolver
RV03
RV0
SinCos safety incremental encoder, single-turn
IG1024-5V-V3
S1S
SinCos incremental encoder, single-turn
IG2048-5V-S
S20
SinCos absolute value encoder, mul-turn,
Hiperface®
AM1024-8V-H
SRM
SinCos absolute value encoder, single-turn,
Hiperface®
AS1024-8V-H
SRS
TTL incremental encoder
IG2048-5V-T
T20
TTL incremental encoder
IG4096-5V-T
T40
Brake Without brake B0
Spring-applied brake DC 24 V F1
Spring-applied brake DC 24 V, reinforced F2
Spring-applied brake AC 230 V FG
Spring-applied brake AC 230 V, reinforced FH
Permanent magnet brake DC 24V P1
Permanent magnet brake DC 24 V, reinforced P2
Permanent magnet brake DC 205 V P5
Permanent magnet brake DC 205 V, reinforced P6
