Lenze MCA Series - Inverter Mains Connection 400 V, Forced Ventilated Motors, Ip23 S

Inverter mains connecon 400 V, Forced venlated motors, IP23s
Product name MCA20X14H MCA20X29H MCA22P08H
Standsll torque M
0
Nm 68.0 68.0 135
Rated torque M
Rated
Nm 61.0 53.5 120
Max. torque M
max.
Nm 250 250 500
Rated speed n
Rated
rpm 1420 2930 760
Max. speed n
max.
rpm 6500 6500 6500
Rated power P
Rated
kW 9.10 16.4 9.60
standsll current I
0
A 26.0 52.0 26.0
Rated current I
Rated
A 23.0 42.4 23.5
Max. current I
max.
A 92.0 170 94.0
Rated voltage V
N, AC
V 350 350 355
Rated frequency f
rated
Hz 50 100 28
Moment of inera J kgcm² 171 171 487
Eciency η
100 %
0.820 0.870 0.800
Stator terminal resistance R
UV 20°C
Ω 0.73 0.18 1.07
Stator terminal resistance R
UV 150°C
Ω 1.10 0.28 1.62
Mutual inductance L
H
mH 60.2 14.3 91.9
Stator leakage inductance L
1σ
mH 2.01 0.50 3.50
Rotor leakage inductance L
2σ
mH 2.14 0.54 4.74
Stator resistance R
1 UV 20°C
Ω 0.37 0.09 0.54
Rotor resistance R
2 UV 20°C
Ω 0.36 0.09 0.48
Mass m kg 64.0 64.0 105
Product name MCA22P14H MCA22P17H MCA22P29H
Standsll torque M
0
Nm 135 135 135
Rated torque M
Rated
Nm 115 112 110
Max. torque M
max.
Nm 500 500 500
Rated speed n
Rated
rpm 1425 1670 2935
Max. speed n
max.
rpm 6500 6500 6500
Rated power P
Rated
kW 17.2 19.6 33.8
standsll current I
0
A 45.1 52.1 90.2
Rated current I
Rated
A 40.0 44.5 77.8
Max. current I
max.
A 160 178 311
Rated voltage V
N, AC
V 360 360 360
Rated frequency f
rated
Hz 50 58 100
Moment of inera J kgcm² 487 487 487
Eciency η
100 %
0.860 0.880 0.890
Stator terminal resistance R
UV 20°C
Ω 0.36 0.27 .09
Stator terminal resistance R
UV 150°C
Ω 0.54 0.40 0.13
Mutual inductance L
H
mH 90.9 23.5 22.9
Stator leakage inductance L
1σ
mH 3.55 0.90 0.90
Rotor leakage inductance L
2σ
mH 4.79 1.22 1.21
Stator resistance R
1 UV 20°C
Ω 0.54 0.13 0.13
Rotor resistance R
2 UV 20°C
Ω 0.48 0.12 0.12
Mass m kg 105 105 105
Technical data
Rated data
Inverter mains connecon 400 V, Forced venlated motors, IP23s
