Product name MCA22P29- MCA26T05- MCA26T10-
Standsll torque M
0
Nm 120 220 220
Rated torque M
Rated
Nm 100 216 210
Max. torque M
max.
Nm 500 1100 1100
Rated speed n
Rated
rpm 2935 550 1030
Max. speed n
max.
rpm 6500 5500 5500
Rated power P
Rated
kW 30.7 12.4 22.7
standsll current I
0
A 80.9 35.4 62.9
Rated current I
Rated
A 72.1 34.9 61.5
Max. current I
max.
A 288 140 246
Rated voltage V
N, AC
V 360 350 350
Rated frequency f
rated
Hz 100 19 35
Moment of inera J kgcm² 487 1335 1335
Eciency η
100 %
0.870 0.830 0.880
Stator terminal resistance R
UV 20°C
Ω .09 0.59 0.20
Stator terminal resistance R
UV 150°C
Ω 0.13 0.89 0.30
Mutual inductance L
H
mH 22.9 66.8 69.2
Stator leakage inductance L
1σ
mH 0.90 2.86 2.93
Rotor leakage inductance L
2σ
mH 1.21 5.04 5.12
Stator resistance R
1 UV 20°C
Ω 0.13 0.29 0.29
Rotor resistance R
2 UV 20°C
Ω 0.12 0.25 0.25
Mass m kg 105 194 194
Product name MCA26T12- MCA26T22-
Standsll torque M
0
Nm 220 220
Rated torque M
Rated
Nm 207 195
Max. torque M
max.
Nm 1100 1100
Rated speed n
Rated
rpm 1200 2235
Max. speed n
max.
rpm 5500 5500
Rated power P
Rated
kW 26.0 45.6
standsll current I
0
A 78.4 125
Rated current I
Rated
A 75.1 113
Max. current I
max.
A 300 452
Rated voltage V
N, AC
V 350 340
Rated frequency f
rated
Hz 41 76
Moment of inera J kgcm² 1335 1335
Eciency η
100 %
0.870 0.920
Stator terminal resistance R
UV 20°C
Ω 0.15 0.05
Stator terminal resistance R
UV 150°C
Ω 0.23 0.08
Mutual inductance L
H
mH 18.1 19.8
Stator leakage inductance L
1σ
mH 0.74 0.78
Rotor leakage inductance L
2σ
mH 1.29 1.29
Stator resistance R
1 UV 20°C
Ω 0.08 0.08
Rotor resistance R
2 UV 20°C
Ω 0.06 0.06
Mass m kg 194 194
Technical data
Rated data
Inverter mains connecon 400 V, Forced venlated motors, IP54
