Product name MCA19S35- MCA21X17- MCA21X35-
Standsll torque M
0
Nm 40.0 75.0 75.0
Rated torque M
Rated
Nm 36.0 61.4 55.0
Max. torque M
max.
Nm 180 300 300
Rated speed n
Rated
rpm 3510 1710 3520
Max. speed n
max.
rpm 8000 8000 8000
Rated power P
Rated
kW 13.2 11.0 20.3
standsll current I
0
A 30.8 25.8 49.5
Rated current I
Rated
A 28.7 22.5 42.5
Max. current I
max.
A 115 90.0 170
Rated voltage V
N, AC
V 390 390 390
Rated frequency f
rated
Hz 120 60 120
Moment of inera J kgcm² 72.0 180 180
Eciency η
100 %
0.850 0.850 0.880
Stator terminal resistance R
UV 20°C
Ω 0.35 0.72 0.18
Stator terminal resistance R
UV 150°C
Ω 0.53 1.09 0.27
Mutual inductance L
H
mH 20.3 68.9 16.8
Stator leakage inductance L
1σ
mH 0.65 2.08 0.52
Rotor leakage inductance L
2σ
mH 0.77 2.58 0.65
Stator resistance R
1 UV 20°C
Ω 0.18 0.36 0.09
Rotor resistance R
2 UV 20°C
Ω 0.15 0.36 0.09
Mass m kg 48.2 63.5 63.5
Product name MCA22P08- MCA22P14- MCA22P17-
Standsll torque M
0
Nm 120 120 120
Rated torque M
Rated
Nm 110 107 106
Max. torque M
max.
Nm 500 500 500
Rated speed n
Rated
rpm 760 1425 1670
Max. speed n
max.
rpm 6500 6500 6500
Rated power P
Rated
kW 8.80 16.0 18.5
standsll current I
0
A 23.4 40.5 46.7
Rated current I
Rated
A 22.1 37.7 42.7
Max. current I
max.
A 88.4 151 171
Rated voltage V
N, AC
V 345 350 360
Rated frequency f
rated
Hz 28 50 58
Moment of inera J kgcm² 487 487 487
Eciency η
100 %
0.800 0.870 0.880
Stator terminal resistance R
UV 20°C
Ω 1.07 0.36 0.27
Stator terminal resistance R
UV 150°C
Ω 1.62 0.54 0.40
Mutual inductance L
H
mH 94.9 94.2 23.4
Stator leakage inductance L
1σ
mH 3.56 3.60 0.90
Rotor leakage inductance L
2σ
mH 4.80 4.85 1.21
Stator resistance R
1 UV 20°C
Ω 0.54 0.54 0.13
Rotor resistance R
2 UV 20°C
Ω 0.48 0.48 0.12
Mass m kg 105 105 105
