Lenze MCA Series - Page 72

Product name MCA14L41- MCA17N23- MCA17N41-
Standsll torque M
0
Nm 8.00 12.8 12.8
Rated torque M
Rated
Nm 5.40 10.8 9.50
Max. torque M
max.
Nm 60.0 100 100
Rated speed n
Rated
rpm 4100 2300 4110
Max. speed n
max.
rpm 8000 8000 8000
Rated power P
Rated
kW 2.30 2.60 4.10
standsll current I
0
A 7.70 6.00 12.0
Rated current I
Rated
A 5.80 5.50 10.2
Max. current I
max.
A 23.2 22.0 40.8
Rated voltage V
N, AC
V 390 390 350
Rated frequency f
rated
Hz 140 80 140
Moment of inera J kgcm² 19.2 36.0 36.0
Eciency η
100 %
0.780 0.860 0.830
Stator terminal resistance R
UV 20°C
Ω 1.50 3.04 0.76
Stator terminal resistance R
UV 150°C
Ω 2.26 4.58 1.15
Mutual inductance L
H
mH 65.8 176 43.4
Stator leakage inductance L
1σ
mH 2.49 6.16 1.54
Rotor leakage inductance L
2σ
mH 2.50 6.84 1.70
Stator resistance R
1 UV 20°C
Ω 0.75 1.52 0.38
Rotor resistance R
2 UV 20°C
Ω 0.78 1.37 0.34
Mass m kg 15.1 22.9 22.9
Product name MCA19S23- MCA19S42- MCA21X25-
Standsll torque M
0
Nm 22.5 22.5 39.0
Rated torque M
Rated
Nm 16.3 12.0 24.6
Max. torque M
max.
Nm 180 180 300
Rated speed n
Rated
rpm 2340 4150 2490
Max. speed n
max.
rpm 8000 8000 8000
Rated power P
Rated
kW 4.00 5.20 6.40
standsll current I
0
A 9.85 19.7 15.9
Rated current I
Rated
A 8.20 14.0 13.5
Max. current I
max.
A 32.8 56.0 54.0
Rated voltage V
N, AC
V 390 330 390
Rated frequency f
rated
Hz 80 140 85
Moment of inera J kgcm² 72.0 72.0 180
Eciency η
100 %
0.900 0.830 0.850
Stator terminal resistance R
UV 20°C
Ω 1.38 0.35 0.72
Stator terminal resistance R
UV 150°C
Ω 2.08 0.53 1.09
Mutual inductance L
H
mH 111 28.0 78.1
Stator leakage inductance L
1σ
mH 3.25 0.82 2.26
Rotor leakage inductance L
2σ
mH 3.90 0.99 2.82
Stator resistance R
1 UV 20°C
Ω 0.69 0.18 0.36
Rotor resistance R
2 UV 20°C
Ω 0.62 0.15 0.36
Mass m kg 44.7 44.7 60.0
Technical data
Rated data
Inverter mains connecon 400 V, Self-venlated motors
72
