Leslie 2102 - Preset Parameters; System Parameters

27
Preset Parameters
Category Parameter
LSB
(62)
MSB
(63)
MSB
(06)
LSB
(26)
Preset1
Preset2
Horn Rotor
Slow Speed
7F 00
0 - 99 (0,24-318rpm) *1 - 5(36rpm) 5(36rpm)
Fast Speed
7F 02
1 - 27(375-450rpm) *2 - 9(400rpm) 7(393rpm)
Rise Time
7F 04
0-39(0.2-12.5s) *5 - 2.2s 1.8s
Fall Time
7F 06
0-39(0.2-12.5s) *5 - 1.2s 1.0s
Brake Time
7F 08
0-39(0.2-12.5s) *5 - 1.4s 1.2
Direction
7F 0C
0,1(Left,Right) - Right Right
Horn Character
7F 0D
0-3 *7 - 1.0k Flat
Low Rotor
Slow Speed
7F 01
0-9(0,24-48rpm) *3 - 5(36rpm) 5(36rpm)
Fast Speed
7F 03
1-21(372-431rpm) *4 - 9(400rpm) 6(391rpm)
Rise Time
7F 05
0-24(0.5-12.5s) *6 - 5.5s 5.0s
Fall Time
7F 07
0-24(0.5-12.5s) *6 - 6.0s 3.0s
Brake Time
7F 09
0-24(0.5-12.5s) *6 - 8.5s 2.0s
Mic Angle
7F 0A
0-6(0
゜ｰ180゜) *8
- 180
゜
120
゜
Mic Distance
7F 0B
0-8(0.2m-2.7m) *9 - 1.8m
1.2m
Horn&Low Rotor
CrossOver Frequemcy
7F 0E
0-2(0.7k,0.8k,1.0k) -
0.7k 0.7k
Cabinet Resonance
7F 0F
0,1(Off,On) - Off On
NRPN Adr. DATA Range
Default
System Parameters
Category Parameter
Default
LSB
(62)
MSB
(63)
MSB
(06)
LSB
(26)
Preset
Preset Number
7F 10
0,1(Preset1,Preset2) - 0(Preset1)
MIDI System
Control Channel
7F 11
0-16(1-16channel,Off) - 0(1Channel)
Program Channel
7F 12
0-16(1-16channel,Off) - 16(Off)
Modulation Receive
7F 13
0,1(Off,On) - 1(On)
Exp Receive
7F 14
0,1(Off,On) - 0(Off)
Slow/Fast Control Type
7F 15
0,1(UnLatch,Latch) - 1(Latch)
Slow/Fast Control Code
7F 16
0-99 - 64
Other
Preset Foot Switch Type
7F 17
0,1(UnLatch,Latch) - 0(UnLatch)
Leslie Mode
7F 18
0-2(Slow,Fast,Brake) - 0(Slow)
NRPN Adr. DATA Range
