SPECIFICATIONS:
Type:
3-channel (ROTARY, STATIONARY-L,
STATIONARY-R)
Animation:
Horn Rotor, Digital Bass Rotor
Power
Output:
Rotary Horn 50W. Stationary Channels
50W×2. 150 watts total.
Speakers:
Compression Driver for Horn,
13cm Woofer × 2, 5cm Tweeter × 2.
Controls:
Volume: STA-L , STA-R , ROTARY ,
OVERDRIVE
8-position Function Selector
Touch Buttons: PRESET 1-2, MEMORY
Channel
Mode:
NORMAL-STA MONO, STA ROT BASS-
MUTE
Display:
7-segment, 2-digit LED display
Terminals:
Leslie 11-pin Receptacle, Leslie 8-pin
Receptacle, ROTARY INPUT, LINE OUT
(STATIONARY-L, STATIONARY-R,
ROTARY-L, ROTARY-R), MIDI IN, MIDI
OUT, REMOTE (Remote Power for #2121).
Foot
Switch:
Foot Switch 1 (PRESET), Foot Switch 2
(SLOW/FAST/STOP)
Powre
Consumption:
AC 120V,220-230V,230-240V 190W.
Dimensions:
51(W)×52(D)×33(H) cm
Weight:
23 kg
Optional
Accessories:
Stationary-Unit #2121, Leslie 11-pin Cable,
Leslie 8-pin Cable (LC8-7M), Stand Adapter,
Foot Switch (FS-9H).
to insure
your
enjoyment
of
performing
music.
The Leslie
®
models 2101, 2102 and 2103 contain
two rotors to produce the world-renowned Leslie
Speaker "Sound-In-Motion
®
." The sound is
"separated" with the highs reproduced by a horn
rotor and the lows reproduced by a two 5" speakers
with electronic rotor capability. Both the
mechanical and electronic rotors can be operated in
two modes - Fast (Tremolo) or Slow (Chorale).
In addition, there is a stationary channel designed to
accommodate the audio signal from another sound
source such as a synthesizer or external sound
module. This audio signal is handled by three
speakers - the two 13cm speakers which also handle
the lower frequencies for the rotary channel, and
two 5cm dome tweeters for the high frequencies.
The Model 2101 cabinet comes in a textured black
finish with side handles for professional portability,
the Model 2102 cabinet is finished in silver and the
Model 2103 is finished in a rich Walnut.
