12.Rotate the fastener in a counterclockwise direction. Remove the fastener and remove the
module - fuel delivery. Remove and discard the o-ring.
13.Drain the remaining fuel from the fuel tank.
Vehicle Coolant - Removal
1. Disconnect the battery - 12V and the battery - high voltage.
2. Remove the cap - expansion tank from the expansion tank - powertrain.
3. Remove the undertray - front.
4. Remove the undertray - centre right.
5. Remove the undertray - centre left.
6.
CAUTION
Prepare to collect the released fluid.
NOTE
The powertrain coolant system contains 18.5 litres of coolant.
Put an applicable container below the radiator to collect the fluid that drains. Remove the
drain plug – radiator.
