Pre-Treatment - First Steps
2
S023735 PB1
2021-10-25
7
CAUTION
Set the ignition to OFF with the rotary switch - start/stop before you start this
procedure.
1. Access the 12V battery. It is located in the right side of the load space above the wheel arch.
Release the seven fasteners and release the cover - battery 12V. Disconnect the electrical
connector from the power outlet - 12V and remove the cover - battery 12V.
2. Disconnect the sensor - battery monitor and the cable - ground - battery 12V from the
battery - 12V and move to one side.
3.
WARNING
Stay a safe distance from the vehicle for a minimum of 5 minutes before
you continue to do work on the vehicle.
