41
Name
VID
Port Members
Marketing
2
1,2,3,4,5
Service
3
6,7,20,21,22
Sales
4
8,9,10,11,12,13,14,15,16
Administration
1
17,18,19,23,24
Table 3-5
Next, assigns IP address to each VLAN. Usually, we use 10.x.x.x as internal
IP block. Because there are total four VLANs in the network, we must assign 4 IP
blocks to each of them.
Name
VID
Network Address
Marketing
2
10.1.2.0/24
Service
3
10.1.3.0/24
Sales
4
10.1.4.0/24
Administration
1
10.1.1.0/24
Table 3-6
Here we apply the subnet mask 255.255.255, and each VLAN is capable of
supporting 254 nodes.
