63
Destination Subnet Mask Gateway Hop Enabled
192.168.1.0 255.255.255.0 192.168.123.216
1

192.168.0.0 255.255.255.0 192.168.123.103
1

So if, for example, Client3 wants to send an IP data packet to 192.168.0.2, it would use the above
table to determine that it had to go via 192.168.123.103 (Router 2)
And if it sends Packets to 192.168.1.11 will go via 192.168.123.216 (Router 1)
Each rule can be enabled or disabled individually.
After routing table setting is configured, click the save button.
