Network Camera User’s Manual
53/54
B. Technical specifications
WCS-6020 WCS-6050
Camera
Image Sensor 2-Megapixel 1/2.7" Progressive CMOS 5-Megapixel 1/3.2" Progressive CMOS
Effective Pixels 1920x1080 2560x1920
Lens Board lens, fixed-focal, f=4.0 mm, F2.0
Angle of View (H)
62 ﾟ
Minimum Illumination
Color: 1.5 lux at F2.0
B/W: 1.0 lux at F2.0
IR Cut Filter Removable infrared-cut filter for day & night function
Shutter Time 1 to 1/10000 sec.
Pan/Tilt/Zoom
Pan range: ±355 ﾟ(-177.5°~177.5°)
Tilt range: ±135 ﾟ (-45°~ 90°)
Auto pan mode
Auto patrol mode
IR LED 12 IR LEDs for illumination up to 10m
Video
Video Compression H.264 / MPEG4 / MJPEG H.264 / MJPEG
Resolutions
1080p(1920x1080) / SXGA(1280x1024) /
WXGA(1280x800) / VGA(640x480) /
QVGA(320x240) / QCIF(176x144)
5M(2560x1920) / 1080p(1920x1080) /
SXGA(1280x1024) / WXGA(1280x800) /
VGA(640x480) / QVGA(320x240) /
QCIF(176x144)
Frame Rate Up to 30 fps at 1920x1080
Up to 10 fps at 2560x1920
Up to 30 fps at 1920x1080
Video Streaming Multiple simultaneous streams, up to 2 streams
Image Setting
- Adjustable image size, quality and bit rate
- Configurable brightness, sharpness, contrast, saturation, white balance and exposure
- AGC/AWB/AES
- Flip & Mirror
- Time Stamp
Video Format AVI
Audio
Audio Streaming 2-way audio
Audio Compression G.726 / AMR
Audio Input/Output
Built-in microphone
Mic/line input, line output
Network
Networking
10/100 Mbps Ethernet, RJ-45
Built-in 802.11b/g/n WLAN
Security
Multi-level user access with password protection
IP address filtering
Supported protocols TCP/IP, HTTP, SMTP, FTP, DDNS, UPnP, Telnet, NTP, PPPoE, DNS, DHCP, RTSP, Samba
Number of clients 20
