Leviton 71D03 - Meter Configuration Overview; Meter Installation Overview

10
3.2 Meter Conguration Overview
Work performed prior to installation saves time, and may result in fewer mistakes.
3.3 Meter Installation Overview
Performed by licensed electrician.
3.4 Verication and Communication Overview
Can be modied when you apply power to the meter.
Tools Typical Work
• Desktop or Laptop PC
• USB
Type AB Cable (preferred) or Ethernet and
USB wall charger (> 500 mA)
• Thumb Drive (Power Meter Viewer Utilities
Installer) or access www.Leviton.com, and go
to software downloads for this product.
• Electrical schematics of project
• Install Power Meter Viewer Utilities Software.
• Connect USB/Ethernet cable from PC to meter.
• Establish communication with meter.
• Firmware update (if required)
• Congure software for anticipated meter setup.
• Field wiring documentation
Tools Typical Work
• Mounting hardware (customer supplied)
•
Wiring, supplies, labels, and wire ties
• Tablet, Smart Device, or Laptop PC
• Multi Meter, Current Clamp
• Camera
• Mechanical mounting.
• Electrical installation.
• Install voltage cover.
• Apply power to meter.
• Conrm basic operation of meter.
Tools Typical Work
• T
ablet, Smart Device (Web Page Based), or
Laptop PC
(Power Meter Viewer Utilities Software)
• On-site troubleshooting
• Multi Meter, Current Clamp
• Camera
• Locate the power meter.
• Conrm RTU device.
• Add wire terminations (if required).
• Conrm meter communication settings.
• Meter health metrics (check for setup errors).
• Analytics (Power Meter Viewer Utilities).
• Correct instrumentation.
• Set security PINs.
• Checklist
3.5 RTU Programming and Scripting Overview
Tools Typical Work
• Laptop PC (Remote Access to RTU)
• R
emote troubleshooting
• Register List
• Conrm meter communication settings.
• Conrm communication protocols.
• Exercise remote connectivity.
• Run conguration scripting.
• Conrm data integrity.
3 PLANNING FOR FIELD INSTALLATION
