About Meter
The complete LCD navigation map is shown in diagram form in the next few pages.
The “About Meter” menu is the most commonly accessed item which requires 5
down presses or 1 up (rolling menu) to access.
The About Meter menu contains the following items which are displayed 4 lines at
a time and accessed by using the up and down keys on the front display.
View Communications
Real Time Values
View Meter Setup
Verify Installation
Log In/Out
About Meter
Main Menu
S7000 v2.00
Serial: P121501001
Model and version
Serial number
State of LAN connection
Current IP address
Current line frequency
Manufacturer name
Copyright notice
Communication protocol
Modbus address
Modbus port
MSTP address
RS485 baud rate
Current DHCP Setting
BACnet Port
BACnet Device ID
Channel 1 pulse accumulator
Channel 2 pulse accumulator
System description
set by user
Current time in UTC (GMT)
MAC Address
LAN: Connected
IP: 10.1.1.1
MC 00:0D:63:00:00:00
Line Frequency: 60.0
Copyright (c) 2018
Protocol: Modbus
Modbus Address: 1
Modbus Port: 502
MSTP Address: 1
Baud Rate: 9600
DHCP: ON
BACnet Port: 47808
BACnet DevID: 527000
Pulse In 1: 0.0
Pulse In 2: 0.0
System Descriptor:
UTC Date / Time:
2018-04-24 10:04:08
Obvius
70x48
8 APPENDIX A: LCD MENU NAVIGATION
