23
This section describes the physical installation of the meter and provides guidance on
connecting the current transformers (CTs) correctly within the electrical load center and
to the VerifEye
®
meter.
5.1 Meter Mounting Congurations
VerifEye
®
meters are sold in several form factors. Enclosures are designed to be
wall mounted and connected to electrical conduit. Plate mounted versions are
ready to be mounted inside a customer supplied NEMA enclosure.
CAUTION: Be careful not to ex the circuit board during mounting.
Cat. 71D48 and 71D24
Cat. 70D48 and 70D24
Cat. 71D12
Cat. 70D12
Enclosure
Plate Mounted
5 METER INSTALLATION
