54
ID FC ADDR DATA CRC
01 06 0A 39 4D 61 AE A7
01 06 0A 3A 69 6E 05 A3
01 06 0A 3B 73 20 DF 37
01 06 0A 3C 62 6C 63 53
01 06 0A 3D 64 20 30 C6
01 06 0A 3E 31 30 FE 5A
01 06 0A 3F 31 20 AE 56
01 06 0A 40 00 00 8B C6
01 06 0A 41 00 00 DA 06
01 06 0A 42 00 00 2A 06
01 06 0A 43 00 00 7B 06
01 06 0A 44 00 00 CA 07
01 06 0A 45 00 00 9B C7
01 06 0A 46 00 00 6B C7
01 06 0A 47 00 00 3A 07
01 06 0A 48 00 00 0A 04
Specic Implementation Examples – Element A Set to ID 1
VIA MODBUS RTU (SERIAL), USING FUNCTION
CODE 6/WRITE SINGLE REGISTER
VIA MODBUS RTU (SERIAL), USING FUNCTION
CODE 16 / WRITE MULTIPLE REGISTER
ID FC ADDR #REGS LN DAT00 DAT01 DATA02 DAT03 DATA04
01 10 0A 39 00 10 20 4D 61 69 6E 73 20 62 6C 64 20
DAT05 DAT06 DAT07 DAT08 DAT09 DAT10 DAT11 DAT12 DAT13
31 30 31 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00
DAT14 DAT15 CRC
00 00 00 00 3A 18
7 RTU PROGRAMMING AND SCRIPTING
