Levitronix PuraLev 2000SU User Manual

User Manual for PuraLev
®
2000SU
www.levitronix.com
PL-4034-00, Rev02, DCO# 20-144
5
System Name
Article #
Pump Head
Socket
Motor
Controller
Note
PLD-2000SU.1
100-90726
PHS-2000.2
LPM-2000.7
LPC-2000.1-04
Adaptor/Extension (0.5 - 10m) cables according to Table 3 (Position 4a and
4b) have to be ordered as separate article with specified length.
ATEX Cable Sealing System can be ordered according to Table 4 (Pos. 7)
Certifications: CE, IECEE (CB scheme), ETL (NRTL), ATEX and IECEx ->
see Section 8.1
PLD-2000SU.2
100-90727
LPM-2000.7
LPC-2000.2-04
PLD-2000SU.3
100-90729
LPM-2000.8
LPC-2000.1-04
PLD-2000SU.4
100-90730
LPM-2000.8
LPC-2000.2-04
Table 1: Standard system configurations
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1a
Single-Use
Pump Head
DCP-2000.2
100-90889
Impeller / Pump Housing
In-/Outlet Fittings
Polypropylene (FDA, USP Class VI, BSE/TSE/Animal free)
(ASME BPE 2009)
Max. Flow
Max. Diff.-Pressure
Max. Viscosity
140 liters/min / 37 gallons/min
4.3 bar / 62.4 psi
50 cP (preliminary Information)
Wet Pump Volume
270 ml / 630 cm
2
Max. Liquid Temp.
60
0
C / 140
0
F
Sterilization Methods
Gamma sterilization with doses up to 40 kGy
1b
Irradiated Pump
Head
DCP-2000.2-G25
100-91080
Applied Gamma Dosage

2a
Motor
(ATEX, IECEx)
LPM-2000.7
100-10059
Housing
- Epoxy (anti-corrosive) coated Aluminum
- waterproofed (IP67)
Cable / Connectors
2x 3m cables with PVC jacket / 2x circular (M23, IP-67)
ATEX/IECEx Marking
II 3G Ex ec h IIC T5 Gc
II 3D Ex h tc IIIC T100°C Dc
2b
Motor
(ATEX, IECEx)
LPM-2000.8
100-10060
Housing
- ETFE (chemical resistant) coated Aluminum
- waterproofed (IP67)
Cable / Connectors
2x 3m cables with FEP jacket / 2x circular (M23, IP-67)
3
Pump Head
Socket
PHS-2000.2
100-90891
Mounting Type
Mounting with 4x M8 screws
Material
Anodized Aluminum
4a
Standalone
Controller
(User Panel)
LPC-2000.1-04
100-30064
(Supply and
Enable
connector
included)
Voltage / Power
1 x 200-240 V AC  10% / 2kW @ 50/60Hz
3 x 200-240 V AC  10% / 2kW @ 50/60Hz
See Section 3.2 for details.
Housing Protection
IP20
Interfaces for
Standalone Controller
Panel to set speed (automatic storage on internal EEPROM)
PLC with
1x analog  4 - 20 mA
 0 - 24 V (optocoupler)
 0 - 24 V (relais)
Standard Firmware
E4.25
4b
Extended
Controller
(PLC and USB)
LPC-2000.2-04
100-30065
(Supply and PLC
connector
included)
Interfaces for
Extended Controller
PLC with
- up to 4 digital inputs 0 - 24V (optocoupler)
- up to 4 digital outputs 0 - 24 V (relais)
- up to 2 analog inputs 4 - 20mA
- up to 2 analog inputs 0  10 V
- up to 2 analog outputs 0  5 V
USB interface (for service and system monitoring)
Standard Firmware
E4.48
Table 2: Specification of standard components
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
5a
Extension Adaptor
Cable for Sensors
MCAS-600.2-05 (0.5m)
MCAS-600.2-30 (3m)
MCAS-600.2-50 (5m)
MCAS-600.2-70 (7m)
MCAS-600.2-100 (10m)
190-10226
190-10238
190-10127
190-10105
190-10239
Jacket Material
Connectors
PVC
Circular Wallmountable, Metallic (IP-67) to D-SUB
5b
Extension Adaptor
Cable for Power
MCAP-2000.2-05
MCAP-2000.2-30
MCAP-2000.2-50
MCAP-2000.2-70
MCAP-2000.2-100
190-10213
190-10215
190-10216
190-10217
190-10218
Jacket Material
Connectors
PVC
Circular Wallmountable, Metallic (IP-67) to COMBICON
Table 3: Specification of adaptor/extension cables
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
6a
Air Cooling Module
ACM-4.2
190-10139
Material / Connection Port

Air Pressure
~1 - 3 bar (14  43 psi)
6b
Air Cooling Module
ACM-4.3
190-10243
Material
PP-EL-S with conductive additive for operation with ATEX motor
7a
Fan Cooling Module
FCM-2000.1
190j-10390
Housing / Cable Spec.
Supply Spec. / IP Rating
PP (+20% Talkum) white / PP jacket, 3m, circular sealed M12 connector (PP).
24 VDC, 33.5 W / IP-65 (fan is IP68 rated).
7b
Fan Cool. Module
Cable
FCC-1.1-50 (5 m)
FCC-1.1-100 (10 m)
190-10407
190-10408
Specification
PP cable jacket with circular M12 connector (PP) to open wires
8
(A-F)
ATEX Cable
Sealing System
ACS-A.1
(Roxtec)
100-90292
Sleeve (A) and Gasket (B)
Frame (C)
2x Cable Module (D)
Stainless Steel and EPDM
Roxylon (EPDM rubber)
Roxylon (EPDM rubber)
Note:
Lubricant (E) and measurement plates
(F) are included.
Table 4: Specification of accessories
