31
N
2 LINK @ SEAT STAY BOLT
SCR,CUST,M6 X 1.0 X
8,SST 30
4 mm HEX 71 8
O
2 Link @ SEAT STAY BOLT AXLE
BOLT,CUST,M6 XIFEM X
22.34, 7075,BLK
6 mm HEX 71 8
P
4 LINK @ SEAT STAY SPACER
SPCR,12.1 ID X 19.5 OD X 3
W,FSR,AL7075-T6
Q
4 LINK @ EXTENSION SPACER
SPCR,CUST, 10 ID X 18.5 OD
X 2.5 W,FSR,AL7075-T73
R
2 LINK @ EXTENSION BOLT
SCR,CUST,M6X1.0 X 8,SST
302
4 mm HEX 71 8
S
2 LINK @ EXTENSION AXLE
AXLE,SS PIVOT,MTB,TRAIL
FSR L1
5 mm HEX 71 8
T
2 LINK @ SEAT TUBE BOLT
SCR ASSY,M12 X 1.0 X 24,PA
TRAIL FSR F1
6 mm HEX 185 21
U
2 LINK @ SEAT TUBE SPACER
SPCR,12.1 ID X 19.5 OD X 3
W,FSR,AL7075-T6
V
2
LINK @ SEAT TUBE CENTER
SPACER
SPCR,12MM ID X 18MM OD X
2MM W,7075-TG
W
1 FORWARD SHOCK EYE BOLT
SCR,CUST,M8X1.0 X 42,CHRO-
MOLY
6 mm HEX 90 10
X
1 REAR SHOCK EYE BOLT
SCR CUST M8Xl.25 X 26 302 SST
SIL HEX 5m
5 mm HEX 185 21
Y
1 REAR SHOCK EYE WASHER
WSHR,FLAT,M8, 8.3 ID X 13 0D X
0.5 THK,304 SST
Z
2
REAR SHOCK EYE TOP HAT
SPACER
SPACER,SHOCK,19X-
8.1X0.6,SST 304
Many bolts have a blue threadlock patch on the threads to help secure the
bolt under torque. Repeated installation and removal of bolts may reduce the
effectiveness of the patch. When that happens, the old threadlocker and any built-
up dirt and grease should be removed and new liquid threadlocker applied.
