16
Figure 4.10
Figure 4.11
Figure 4.12
Figure 4.13
f. Remove the float from the base
chamber by pulling up one
end of the float [Figure 4.11] and
pulling the shaft out from the float
brackets. One side of the float
brackets is open (U-shaped) to
allow the shaft to be removed.
[Figure 4.12]
e. Flip the tank over and remove
the noise silencer. To remove the
noise silencer, press the release
tabs and gently pull away from the
humidifier. [Figure 4.10]
g. Place the float, water filter
assembly, and noise silencer in a
small container. Fill with enough
vinegar to cover them. Soak for
1520 minutes. [Figure 4.13]
d. Remove the tank, remove the tank
cover, and pour out any vinegar.
[Figure 4.9]
Cleaning (cont.)
Figure 4.9
