Installation Overview
■
Your order will include the correct number of installation brackets for your shade width, as shown in the table.
➤
There are two sizes of installation brackets, one for
3
⁄
8
" and
3
⁄
4
" cell sizes and a larger one for the 1
1
⁄
4
" cell size.
➤
For end mounts, only two brackets are used up to the maximum width of 72".
Mounting Types and Window Terminology
If the installation brackets are mounted correctly, the rest of the installation process follows easily. To prepare for this important
first step, review the mounting types and basic window terminology illustrated below.
■
Refer to the appropriate page below based on your order:
➤
Inside Mount — page 3
➤
Outside Mount — page 4
➤
End Mount — page 6
Installation
Bracket
End Mount
Brackets
Outside Mount
Shade mounts
outside
window opening.
Inside Mount
Shade fits within
window opening.
Collectively, the sill and
jambs are called the
“window casement.”
Molding
Head Jamb
Sill
Jamb Jamb
