INSTALLATION
INSTALLATION
Install the Wand
The wand must be securely attached t the shade for proper operation.
■
Gently pull out the bumper and threaded connector until it is visible.
■
Slide the bumper away from the treaded connection.
CAUTION: Do not grip the bumper on top of the connector and attempt to
screw on the wand at this point. Secure attachment of the wad cannot be
guaranteed if tightened by hand.
■
Hold the threaded connector with a 5/16” (8mm) open end wrench, and screw the
hollow end of the wand onto the threaded connector, as show. If necessary, pliers
can be used instead of a wrench.
➤
Continue to firmly rotate the wand until you feel it click two times and the wand
stops moving. This ensures the wand is securely attached.
CAUTION: If the wand is not properly secured, it will come loose after repeated
use.
■
Slide the bumper back onto the treaded connector.
➤
Make sure the bumper is properly aligned and seated tightly on top of the threaded
connector.
NOTE: The underside of the bumper matches the shape on the top of the threaded
connector.
■
Gently release the wand.
Bumper
Connector
Aligned
