Lewmar V1-6 Windlass ref 65001201 iss.8 | 27
V23 PARTS LIST
KIT NO. DESCRIPTION ITEMS INCLUDED QTY.
66000060 Cap Kit 22(1), 5(1)
66000624 V1/V2/V3 Base 3(1), 10(1), 35(1)
66000625 Chain Pipe Cover 11(1), 34(2)
66000626 Fastener Kit 1(1), 2(1), 4(3), 5(1), 6(1), 8(1), 17(1), 28(1), 33(1), 34(2)
66000641 Drive Kit V2/V3 Gypsy Only 1(1), 2(1), 3(1), 4(3), 5(1), 14(1), 15(2), 17(1), 35(1)
66000628 Manual Recovery Pawl Kit (Fall Safe) 12(1), 18(1), 19(1), 28(1), 29(1), 33(1)
66000640 Drum Kit V2/V3 Fast Fit 38(1), 39(1), 40(1)
66000065 Drum Top Nut 39(1), 40(1)
66000642 Drive Kit V2/V3 Gypsy Drum 1(1), 2(1), 3(1), 4(3), 5(1), 14(1), 15(2), 17(1), 35(1)
66000631 Mounting Kit (Metric) 9(1), 16(1), 20(1), 26(4), 27(4)
66000632 Fast Fit Assembly 36(1), 37(1)
66000633 Deck Spacer Kit 13(1), 32(4)
66200076 Sensor & Magnet Kit 21(1), Magnet(1)
66810030 Control Arm Kit 7(1), 8(1), 23(1)
66840054 Manual Recovery Kit (Gypsy Only) 4(1), 24(1), 25(1)
68000360 V Range Gypsy & Stripper Kit (000) 31(1), Magnet(1)
68000361 V Range Gypsy & Stripper Kit (001) 31(1), Magnet(1)
68000362 V Range Gypsy & Stripper Kit (002) 31(1), Magnet(1)
68000363 V Range Gypsy & Stripper Kit (003) 31(1), Magnet(1)
68000813 12V V2 Fast-Fit Motor Gearbox Assembly 30(1), 36(1), 37(1)
68000814 24V V2 Fast-Fit Motor Gearbox Assembly 30(1), 36(1), 37(1)
68000815 12V V3 Fast-Fit Motor Gearbox Assembly 30(1), 36(1), 37(1)
68000816 24V V3 Fast-Fit Motor Gearbox Assembly 30(1), 36(1), 37(1)
68000817 12V V2 M/O Ride Motor Gearbox Assembly 30(1), 36(1), 37(1)
68000818 24V V2 M/O Ride Motor Gearbox Assembly 30(1), 36(1), 37(1)
68000819 12V V3 M/O Ride Motor Gearbox Assembly 30(1), 36(1), 37(1)
68000820 24V V3 M/O Ride Motor Gearbox Assembly 30(1), 36(1), 37(1)
66840056 V2/V3 Gypsy/Drum Manual Recovery Kit Not Shown
