Lewmar V1-6 Windlass ref 65001201 iss.8 | 29
KIT NO. KIT DESCRIPTION ITEMS INCLUDED QTY.
66000065 Drum Top Nut 24(1), 25(1)
66000070 Fastener/Drive
2(1), 3A(1), 3B(1),6(1), 7(1), 18(1), 19(1), 21(1), 24(1), 28(1), 29(1),
32(4), 33(8), 37(1), 38(1), 40(5), 43(4), 44(4), 45(4),
Hex Keys 2, 4, 5 & 6 mm
66000071 Mainshaft Assembly, Gypsy/Drum 4A(1), 13(1)
66000072 Mainshaft Assembly, Gypsy Only 4B(1), 13(1)
66000073 Bearing/Seal 5(1), 8(1), 12(1), 12A(1)
66000075 Stripper/Pawl
15(1), 16(1), 26(1), 28(1), 29(1), 37(1), 38(1), 39(1), Hex Keys 2, 4, 5
& 6 mm
66000076 Base 5(1), 9(1)
66000077 Chain Pipe Cover 17(1), 18(1), 19(1), Hex Key 5 mm
66000079 Spacer 3B(1), 30(1), 31(1), 32(4), 33(8)
66810031 Control Arm Kit
34(1), 35(1), 36(1),
Hex Keys 4, 5 & 6 mm
66200076 Optional Sensor & Magnet Sensor(1), Magnet(1) & Housing(1)
