Lewmar V8 User Manual

14
Thermal Switch
Reed Switch Sensor for Chain Counter (If fitted)
Control Box
(24 V - 68000130)
Circuit Breaker
2.5 kW - 200 A - 68000894 3.5 kW - 250 A - 68000895
Battery
Isolator
Battery
24 VDC
Control Box
(24 V - 18000237)
Contactor
(24 V - 68000321)
Contactor
(24 V - 68000319)
Electric Deck Switches
Rocker
Switches
Electric Remote
Control
Thermal
Switch
Fuse
3 A
V8 3.5 kW - 24 VDC
V8 2.5 kW - 24 VDC
V8 2.5 kW - 24 VDC
V8 3.5 kW - 24 VDC
4
5
6
4 5 6
4 5 6
4 5 6
4 5 6
1
2
3
1
2
3
1
2
3
1
2
3
1 2 3
Wireless Remote
Control
Part No. 68000967
UP
DOWN
UP
DOWN
ON
GB
4.5 V8 Wiring diagram
V8 windlass models
Switch wire thickness: 1.5 mm² (16 AWG)
