Lewmar V8 User Manual

20
3
ON
6.4-1
6.5-2
ON
6.6-3 6.6-4
GB
6.4 Power up/down
NOTE: Ensure that the band brake is released and that the dog drive is fully engaged.
1. Press the deck switch, remote control or toggle switch (anchor up/down).
Note: As anchor approaches the vessel use careful adjustments of controls to avoid damaging vessel
6.5 Braked anchor free-fall
NOTE: Ensure that the dog drive is fully released and band brake is fully tightened.
2. Using a Lewmar winch handle carefully release the brake to allow the gypsy to run free. The descent of the
chain can be controlled and stopped by tightening the band brake.
6.6 Independent capstan/warping operation
NOTE: Ensure that the dog drive is fully released and band brake is fully tightened.
3. For temporary use of capstan, ensure chain is adequately secured to an independent strong point.
4. Wrap at least 3 coils of rope, loosely around capstan drum.
• Press the UP button to power the capstan and apply tension to rope gently.
• If warping speed is too fast, ease tension with rope.
6.7 Servicing schedule
Regularly:
• Wash down the windlass using fresh water.
• Examine all electrical connections for corrosion,
clean and lightly grease.
Annually:
• Check electric cables for damage.
Repair/renew as required.
• Strip the above deck components, clean and lightly
grease.
DO NOT wrap chain
around the capstan drum
