Lexicon MPX 100 User Manual

Flange
In the MPX 100, the stereo Flanger has
two 2-tap delays —one per channel. The first
tap is fixed, and the second sweeps past it.
Mixing the two delay taps together creates
the flanging effect.
All of the variations of this program (9-16)
should be used with Mix set to fully Wet to
achieve the full flange effect.
27
Flanging effects were originally created by simultaneously recording and
playing back two identical programs on two tape recorders, then using hand
pressure against the flange of the tape reels to slow down first one machine, then
the other. The result was a series of changing phase cancellations and reinforce-
ments, with a characteristic swishing, tunnelling and fading sound.
Flange VARIATIONs Adjust Tap
9 Light Flange: in phase sweep ± Resonance —
10 Light Flange: out of phase sweep ± Resonance —
11 Light Flange: in phase sweep Rate —
12 Light Flange: out of phase sweep Rate —
13 Deep Flange: in phase sweep ± Resonance —
14 Deep Flange: out of phase sweep ± Resonance —
15 Light Flange Sweep: 0, 90, 180, 270 —
16 Deep Flange Sweep: 0, 90, 180, 270 —

Lexicon MPX 100 Specifications

Audio Inputs and Outputs

audio input level	-30dBu to +4dBu
audio input impedance	500K unbalanced
audio output level	+8dBu typical
audio output impedance	75Ω for Headphone output

Digital Audio

digital audio output	20-bit Digital S/PDIF
sample rate	44.1kHz
conversion	20 bits A/D, 20 bits D/A

Frequency and Distortion

frequency response	20Hz-20kHz, ±1dB
thd+n	<0.05%, 20Hz-20kHz
dynamic range A/A	>95dB typical, 20Hz-20kHz, unweighted
dynamic range A/D	>100dB typical, 20Hz-20kHz, unweighted
crosstalk	45dB

Power and Environment

power requirements	9VAC wall transformer
operating temperature	32° to 104°F (0° to 40°C)
relative humidity	95% non-condensing

Weight and Dimensions

dimensions	19"W x 1.75"H x 4"D (483 x 45 x 102mm)
weight	2 lbs, 2 oz (0.959kg)
internal audio data path	DSP: 24-bit
