Lexicon MPX 100 User Manual

Pitch
The stereo polyphonic Pitch program in
the MPX 100 allows complete program ma-
terial or monophonic sources to be shifted
down two octaves or up one octave.
For pitch correction, use this algorithm
with Mix set to fully Wet. For harmonization,
use the desired amount of wet/dry Mix.
28
Altering the pitch of a sound allows a variety of effects from subtle detuning to
the creation of harmonies and chords.
Pitch VARIATIONs Adjust Tap
1 Semi-tone Shift -2 to +1 octaves —
2 Glide Shifter ± 1 octave —
3 +/-100 cents ± 100 cents —
4 Minor 3rd to 4th Harmony Flat 3rd to 4th Up —
5 4th/5th Harmony 4th to 5th Up —
6 5th/6th Harmony 5th to 6th Up —
7 2nd Inversion Triad Minor/Major 3rd —
8 Power Chords Inversion —

Lexicon MPX 100 Specifications

Audio Inputs and Outputs

audio input level	-30dBu to +4dBu
audio input impedance	500K unbalanced
audio output level	+8dBu typical
audio output impedance	75Ω for Headphone output

Digital Audio

digital audio output	20-bit Digital S/PDIF
sample rate	44.1kHz
conversion	20 bits A/D, 20 bits D/A

Frequency and Distortion

frequency response	20Hz-20kHz, ±1dB
thd+n	<0.05%, 20Hz-20kHz
dynamic range A/A	>95dB typical, 20Hz-20kHz, unweighted
dynamic range A/D	>100dB typical, 20Hz-20kHz, unweighted
crosstalk	45dB

Power and Environment

power requirements	9VAC wall transformer
operating temperature	32° to 104°F (0° to 40°C)
relative humidity	95% non-condensing

Weight and Dimensions

dimensions	19"W x 1.75"H x 4"D (483 x 45 x 102mm)
weight	2 lbs, 2 oz (0.959kg)
internal audio data path	DSP: 24-bit
