Lexicon MPX 100 User Manual

Detune
The 4-voice stereo Detune program in
the MPX 100 has one pair of voices per
channel. As more detune amount is applied
(with Adjust), the pair grow more out of tune,
providing a lush sound without the need for a
dry signal to be mixed in.
All of the variations of this program (9-16)
should be used with Mix set to fully Wet to
achieve the full effect.
29
Detune effects add a delayed/pitch shifted version of the original source —
thickening up the sound. They can be particularly effective when used to simulate
double-tracking. They are also great alternatives to chorus effects, adding the
richness of a chorus without the audible sweep caused by the chorus rate.
Detune VARIATIONs Adjust Tap
9 Mild Detuning –
10 Moderate Detuning –
11 Heavy Detuning –
12 FullRange Detuning –
13 Warm & Mild Detuning –
14 Warm & Moderate Detuning –
15 Warm & Heavy Detuning –
16 Slap Detuner Detuning –

Lexicon MPX 100 Specifications

Audio Inputs and Outputs

audio input level	-30dBu to +4dBu
audio input impedance	500K unbalanced
audio output level	+8dBu typical
audio output impedance	75Ω for Headphone output

Digital Audio

digital audio output	20-bit Digital S/PDIF
sample rate	44.1kHz
conversion	20 bits A/D, 20 bits D/A

Frequency and Distortion

frequency response	20Hz-20kHz, ±1dB
thd+n	<0.05%, 20Hz-20kHz
dynamic range A/A	>95dB typical, 20Hz-20kHz, unweighted
dynamic range A/D	>100dB typical, 20Hz-20kHz, unweighted
crosstalk	45dB

Power and Environment

power requirements	9VAC wall transformer
operating temperature	32° to 104°F (0° to 40°C)
relative humidity	95% non-condensing

Weight and Dimensions

dimensions	19"W x 1.75"H x 4"D (483 x 45 x 102mm)
weight	2 lbs, 2 oz (0.959kg)
internal audio data path	DSP: 24-bit
