Lexicon MPX 100 User Manual

35
Pitch – Delay
Pitch-Delay VARIATIONs Adjust Tap Routing
1 5th Up/Down - Stereo Quarter-Note ± 5th Delay Time
2 Octave Up/Down - Triplet Shuffle ± 1 octave Delay Time
3 Octave Up/Down - Eighth and Triplet ± 1 octave Delay Time
4 3rd Up/4th Up - Ping Pong Quarter-Note Minor 3rd to 4th Up Delay Time
5 4th Up/5th Up - Triplet Rhythm 1 4th to 5th Up Delay Time
6 5th Up/6th Up - Triplet Rhythm 2 5th to 6th Up Delay Time
7 Octave Up/Down > Triplet Rhythm 1 ± 1 octave Delay Time
8 5th Up/Down > Triplet Rhythm 2 ± 5th Delay Time
9 Major/Minor Minor/Major 3rd w/Feedback Delay Time
10 Intervals Up Ascending Intervals w/Feedback Delay Time
11 5th Up/Down + Stereo Quarter-Note ± 5th Delay Time
12 Octave Up/Down + Triplet Shuffle ± 1 octave Delay Time
13 4th Up/5th Up + Triplet Rhythm 1 4th to 5th Up Delay Time
14 5th Up/6th Up + Triplet Rhythm 2 5th to 6th Up Delay Time
15 Octave Up/Down / Mono Quarter-Note ± 1 octave Delay Time
16 Octave Up/Down / Triplet Shuffle ± 1 octave Delay Time

Lexicon MPX 100 Specifications

Audio Inputs and Outputs

audio input level	-30dBu to +4dBu
audio input impedance	500K unbalanced
audio output level	+8dBu typical
audio output impedance	75Ω for Headphone output

Digital Audio

digital audio output	20-bit Digital S/PDIF
sample rate	44.1kHz
conversion	20 bits A/D, 20 bits D/A

Frequency and Distortion

frequency response	20Hz-20kHz, ±1dB
thd+n	<0.05%, 20Hz-20kHz
dynamic range A/A	>95dB typical, 20Hz-20kHz, unweighted
dynamic range A/D	>100dB typical, 20Hz-20kHz, unweighted
crosstalk	45dB

Power and Environment

power requirements	9VAC wall transformer
operating temperature	32° to 104°F (0° to 40°C)
relative humidity	95% non-condensing

Weight and Dimensions

dimensions	19"W x 1.75"H x 4"D (483 x 45 x 102mm)
weight	2 lbs, 2 oz (0.959kg)
internal audio data path	DSP: 24-bit
