Lexicon MPX G2 Service Manual

MPX G2 Service Manual
7-6
PART NO. DESCRIPTION QTY EFFECTI
■
INACTIVE REFERENCE
510-12874 CONN,POST,100X025,HDR,2MC,PCRA 2.00 J3,4
710-11529 PC BD,FP POT,MPXG2 1.00
Front Panel Input Board
202-11074 RESSM,RO,5%,1/4W,510 OHM 1.00 R3
203-10896 RESSM,RO,1%,1/10W,1.00K OHM 1.00 R2
203-11744 RESSM,RO,1%,1/10W,1.00M OHM 1.00 R1
244-10423 CAP,MYL,.22UF,10%,RAD 1.00 C1
245-09895 CAPSM,CER,10pF,50V,COG,10% 1.00 C4
245-10562 CAPSM,CER,150pF,50V,COG,10% 1.00 C5
245-12485 CAPSM,CER,.1uF,25V,Z5U,20% 2.00 C2,3
270-11545 FERRITESM,CHIP,600 OHM,0805 1.00 FB1
300-10563 DIODESM,DUAL,SERIES,GP,SOT23 1.00 D1
340-11573 ICSM,LIN,NJM4580,DUALOPAMP,SOP 1.00 U1
510-10546 CONN,POST,079,HDR,4MC 1.00 J1
510-11582 1/4"PH JACK,PCRA,2C,SW-T,G,PT 1.00 J4
510-12874 CONN,POST,100X025,HDR,2MC,PCRA 2.00 J2,3
710-11531 PC BD,FP INPUT,MPXG2 1.00
Chassis/Mechanical
430-12512 DISP,VF,16X2CHAR,5X7DOT 1.00 TO MAIN BD (J20)
454-11095 SW,ROCKER,1P2T,6A@250,VERTSLIM 1.00 POWER SWITCH
550-11063 KNOB,.84,6MM/FL,BLK 1.00 ENCODER
550-11560 KNOB,.43X.65,6MM/FL,BLK,LINE 3.00 LEVEL POTS
550-11561 KNOB,.43X.48,6MM/FL,BLK,LINE 2.00 CONCENTRIC POT,
REAR LEVEL POT
550-11562 KNOB,.61,8MM,CONC,BLK,LINE 1.00 CONCENTRIC POT
630-11484 GASKET,KEYPAD,3X3,MPX 1 1.00 SWITCH ASSY
640-10467 SCRW,M3X6MM,FH,PH,BZ 4.00 FP ASSY TO CHASSIS
& INSERT
640-10498 SCRW,M3X6MM,PNH,PH,BZ 16.00 MAIN BD TO CHAS (4);
PWR SUP TO CHAS (4);
CVR TO CHAS REAR(4);
BRACKET TO COVER/
CHASSIS/INSERT (4)
641-11466 SCRW,TAP,#4X3/8,PNH,PH,BZ,TRI 4.00 XLR CONN TO CHASSIS
641-11834 SCRW,TAP,AB,#2X1/4,PNH,PH,ZN 5.00 DIN CONN TO CHAS(3);
DISPLAY TO INSERT(2)
643-10492 NUT,M4X.7MM,KEP,ZN 1.00 CHASSIS GND
644-01747 WSHR,INT STAR,#4,ZN 1.00 PWR SUP GND
644-10494 WSHR,FL,M4CLX9ODX.8MM THK 1.00 CHASSIS GND
650-10427 RVT,SNAP-IN,.12DIA,NYL 5.00 SW ASSY (3) & DSPLY
BD (2) TO INSERT
680-11295 CABLE,079,SCKT/SCKT,16C,2.5" 1.00 SW ASSY TO
MAIN BD (J20)
680-12480 CABLE,AC PWR,2C,SHLD,12.75" 1.00 PWR SUP TO AC CONN
& PWR SW
680-12516 CABLE,RIB,24G,14CX.1,3.25"L 1.00 DISPLAY TO MAIN BD
680-12870 CABLE,079,SCKT/SCKT,12C,2.5" 1.00 POT BD (J1) TO
MAIN BD (J17)
680-12871 CABLE,079,SCKT/SCKT,4C,3" 1.00 FP INPUT BD (J1) TO
POT BD (J2)
680-12872 CABLE,COAX,.100,SCKTX2,2C,2.5" 1.00 POT BD (J3) TO
MAIN BD (W3)
680-12873 CABLE,COAX,.100,SCKTX2,2C,10" 3.00 FP INPUT BD (J2) TO
MAIN BD (J22);
MAIN BD (J21) TO
POT BD (J4);
FP INPUT BD (J3) TO
MAIN BD (W1)
700-11555 CHASSIS,INSERT,FP,MPXG2 1.00
700-11556 CHASSIS,1UX12,MPXG2 1.00
700-12479 COVER,TOP,1UX12 1.00
701-11061 BRACKET,MTG,RACK,1U,MPX 1 2.00
702-11490 COVER,PROT,PS,2.9X5.7 1.00
