Lexicon MPX G2 Service Manual

Lexicon
7-5
PART NO. DESCRIPTION QTY EFFECTI
■
INACTIVE REFERENCE
U38-40,45,48-50,53
U55-57,59,62,63,65
U66,72-74
340-11574 ICSM,LIN,TLC2272,DUALOPAMP,SOP 1.00 U33
340-11597 ICSM,LIN,TL072,DUAL OPAMP,SOIC 2.00 U25,46
340-12936 ICSM,LIN,OPA2134,DU OP AMP,SO8 2.00 U19,47
340-13540 IC,LINEAR,LM2940C,5V REG,TO220 2.00 10/06/98
■
U30,71
346-10507 ISCM,SS SWITCH,74HC4051,SOIC 1.00 U96
346-10508 ICSM,SS SWITCH,74HC4053,SOIC 9.00 U18,22,27,28,37,52
U58,60,61
346-12489 ICSM,SS SWITCH,74HC4052,SOIC 2.00 U51,54
350-11046 ICSM,SRAM,32KX8,85NS,SOIC,20UA 1.00 U89
350-11084 ICSM,FPGA,3042A,10X10,7NS,PLCC 1.00 U84
350-11540 IC,FLASH,4M,MPXG2,V1.00 1.00 U93
350-12384 ICSM,DRAM,1MX4,60NS,SOJ 5.00 U78-82
355-11581 ICSM,DIGI-POTX2,AUDIO,45K,SOP 9.00 U3,12-14,31,41-44
355-12333 ICSM,DAC,CS4390,24BIT,STR,SSOP 2.00 U67,75
355-13141 ICSM,ADC,CS5360,24BIT,STR,SSOP 2.00 U64,76
365-11092 ICSM,UPROC,Z80,CMOS,10MHz,PLCC 1.00 U90
365-11898 ICSM,uPROC,ADSP2186,TQFP 1.00 U88
375-12982 IC,OPTO-ISOL,HCPL2601 1.00 U9
390-12144 CRYSTALSM,16.000MHz,PAR,18pF 1.00 Y2
390-12385 CRYSTALSM,10.000MHz,PAR,HC49 1.00 Y3
390-12386 CRYSTALSM,22.5792MHz,PAR,HC49 1.00 Y1
410-03584 RELAY,2P2T,LOW LEVEL,DIP,12V 1.00 RY1
430-10419 LEDSM,INNER LENS,RED 2.00 D39,40
460-04285 BAT,LITH,3V@160mAh,VERT COIN 1.00 BAT1
510-06042 CONN,DC POWER,PC,DJ005,2.5MM 1.00 J15
510-09790 CONN,DIN,5FC@180DEG,PCRA,SHLD 2.00 J12,13
510-10745 CONN,POST,100X025,HDR,2MC,POL 4.00 J21,22;W1,3
510-10881 CONN,XLR,3MC,PCRA,PLASTIC CMPT 2.00 J2,5
510-10984 CONN,JMP,.6X2.5MM,16FC,TRAP 1.00 J19
510-11049 CONN,DIN,7FC@270DEG,PCRA,SHLD 1.00 J14
510-11087 1/4"PH JACK,PCRA,3C,SW-TR,G,FT 5.00 J3,4,6,10,11
510-11390 CONN,POST,079,HDR,16MC,LC 1.00 J20
510-11548 1/4"PH JACK,PCRA,2C,SW-T,G,FT 2.00 J1,7
510-11549 1/4"PH JACK,PCRA,2C,SW-TS,FT 2.00 J8,9
510-11585 CONN,POST,079,HDR,12MC,LC 2.00 J17,18
520-09736 IC,SCKT,32 PIN,PC,TIN,LO-PRO 1.00 U93
680-11067 CABLE,.156,HSG/ST&T,6C,9.5" 1.00 J16
701-12859 SHIELD,1/4"PH JACK,.76X.9X.55 1.00 OVER J1
704-06165 HEAT SINK,TO-220,AAVID 5968B 2.00 U30,71
710-11520 PC BD,MAIN,MPXG2 1.00
■
10/06/98 REV 6 PC BOARD
710-11520 PC BD,MAIN,MPXG2 1.00 10/06/98
■
REV 7 PC BOARD
720-03571 TAPE,KAPTON,1/2" 0.00
■
10/06/98 RY1/C38 RESISTOR
740-11287 LABEL,S/N,PCB,PRINTED 1.00
Display Board
430-11088 LED,DSPLY,7-SEG,GRN,3DIG,.56 1.00 DISP1
680-11587 CABLE,079,SCKT/SCKTRA,12C,2.5" 1.00 J1
710-11530 PC BD,DSPLY,MPXG2 1.00
MPX G2 FRONT PANEL POT BOARD
200-11570 POT,RTY,CONC,10K25AX3,12,35L 1.00 R4
200-12173 POT,RTY,PC,10KBX2,6MMFL,16,30L 3.00 R1-3
240-11827 CAPSM,ELEC,10uF,16V,20% 1.00 C1
245-12485 CAPSM,CER,.1uF,25V,Z5U,20% 2.00 C2,3
340-11573 ICSM,LIN,NJM4580,DUALOPAMP,SOP 1.00 U1
430-07325 LED,RED,T1,LITON 1.00 D1
430-07326 LED,GRN,T1,LITON 1.00 D2
510-10546 CONN,POST,079,HDR,4MC 1.00 J2
510-11585 CONN,POST,079,HDR,12MC,LC 1.00 J1
