MPX G2 Service Manual
7-4
PART NO. DESCRIPTION QTY EFFECTI
■
INACTIVE REFERENCE
C116,120,121,123-129
C131,132,137,138,140
C141,143,144,147,149
C160-164,166,169-171
C173-176,178-181,183
C184,186-192,194
C197-199,202-204
C206-209,211,214,216
C217,222,223,229,230
C232,233,235,236,240
C242-248,251-254
C256-259,263,264,266
C267,271,272,276,277
C281,282,289,290,298
C299,301,304,306,310
C313,316,319,320
C323-325,328,329
C334-337,342,343,347
C348,353,357-362
C364-370,373-381
C384-386,389-394
C396-402,405,407-412
C418,419
245-12486 CAPSM,CER,5600pF,50V,COG,20% 7.00
■
08/18/98 C89,286,288,295
C297,339,341
245-12487 CAPSM,CER,.018uF,50V,COG,10% 1.00 C224
245-12488 CAPSM,CER,.022uF,50V,COG,10% 1.00 C228
245-12522 CAPSM,CER,120pF,50V,COG,10% 2.00 C83,212
245-12524 CAPSM,CER,68pF,50V,COG,5% 3.00 C21,25,213
245-12962 CAPSM,CER,5600pF,50V,COG,5% 7.00 08/18/98
■
C89,286,288,295
C297,339,341
270-06671 FERRITE CHOKE,2.5 TURN 2.00 FB15,16
270-11545 FERRITESM,CHIP,600 OHM,0805 14.00 FB1-14
300-10509 DIODESM,1N914,SOT23 18.00 D20,29-31,41,52,53
D58-65,67-69
300-10563 DIODESM,DUAL,SERIES,GP,SOT23 40.00 D1-11,14-19,23-28
D32,33,36-38,42-51
D54,55
300-11599 DIODESM,GP,1N4002,MELF 7.00 D21,22,34,35,56,57
D66
310-10422 TRANSISTORSM,2N4403,SOT23 13.00 Q3,21,24,28,33,52-59
310-10510 TRANSISTORSM,2N3904,SOT23 14.00 Q9-13,17,18,26,31
Q32,35,38,41,60
310-10565 TRANSISTORSM,2N3906,SOT23 10.00 Q8,16,25,27,30,39
Q40,42,43,61
310-10566 TRANSISTORSM,2N4401,SOT23 13.00 Q4,22,23,29,34,44-51
310-12196 TRANSISTORSM,J108,N-CH,SOT23 11.00 Q1,2,5-7,14,15,19
Q20,36,37
330-09350 IC,DIGITAL,LEXICHIP 2 1.00 U85
330-09877 ICSM,DIGITAL,74HC174,SOIC 2.00 U86,87
330-10417 ICSM,DIGITAL,74HC00,SOIC 1.00 U83
330-10523 ICSM,DIGITAL,74HCU04,SOIC 1.00 U95
330-10527 ICSM,DIGITAL,74HC138,SOIC 2.00 U92,94
330-10533 ICSM,DIGITAL,74HC245,SOIC 1.00 U102
330-10534 ICSM,DIGITAL,74HC259,SOIC 1.00 U91
330-10535 ICSM,DIGITAL,74AC273,SOIC 1.00 U103
330-10536 ICSM,DIGITAL,74HC273,SOIC 4.00 U97-99,101
330-11094 ICSM,DIGITAL,74HC257,SOIC 2.00 U100,104
340-00742 IC,LINEAR,7805 (LM 340 T-5) 2.00
■
10/06/98 U30,71
340-01525 IC,LINEAR,7905,-5V REG 2.00 U29,70
340-07726 IC,LINEAR,LM337T,TO-220 2.00 U11,69
340-08225 IC,LINEAR,LM317T,TO-220 2.00 U10,68
340-10567 ICSM,LIN,MC34164,+5V MON,SOIC 1.00 U77
340-10877 ICSM,LIN,4556,DUAL OP AMP,SOIC 3.00 U2,4,5
340-11045 ICSM,LIN,LM393,DUAL COMP,SOIC 2.00 U8,24
340-11573 ICSM,LIN,NJM4580,DUALOPAMP,SOP 33.00 U1,6,7,15-17,20,21
U23,26,32,34-36
